High speed printing model for receipt printing
3 inch KIOSK printer

NP-3C11DK

  • 203dpi
  • 24V駆動
  • USBインターフェイス
  • オートカッタ
  • シリアルインターフェイス
  • 厚紙
  • Paper width 76mm
  • Paper width 80mm
  • Paper-width 82.5mm
NP3C11DK_Eng

Product featuresProduct features

  1. High speed 350mm/sec. at maximum printing
  2. Applicable for the thick paper (Paper thickness: 59 to 150 micrometres)
  3. Operating temperature: -20 to +60 degrees Celsius
  4. Optional LED bezel or presenter is attachable.
  5. It is equipped with "Mega Font" which has almost 2 times many dots as those of regular fonts.
    It realizes large and clear text printing.
  6. Supporting 2D barcodes (QR code model2, PDF417, Split QR codes model2 and Micro QR code) printing

Main specificationsMain specifications

Model name NP-3C11DK
Print speed 350 mm/sec.
Number of dots / Line 640 dots
Paper width 76 , 80 , 82.5 mm
Print width 80 mm (at max.)
Paper diameter 83 mm
Character International, English, Chinese, Korea, Greek, Polish, Russian, Scandinavian, Turkish, Japanese
Barcode UPC-A, UPC-E, EAN-8, EAN-13, CODE39, CODABAR, ITF, CODE128, CODE93, GS1 DataBar, QR code (model2), Split QR codes (model2), Micro QR code
Interface USB (V2.0 Full Speed) and Serial (RS232C)
Cutter Full cut and Partial cut by the command
External dimensions 120.8 (W) x 187.4 (D) x 88.1 (H) mm
Options PS11-E2/U2, NPT-308L/308LL, BEZ-333, BEZ-232/233

InquiryInquiry

If you have any question, please contact us.

OptionOption

Model name：PS11-E2/U2

  1. Power supply DC24V
  2. 2 pin converter is bundled.
See more details of the productSee more details of the product

Model name：NPT-308L

  1. Paper retraction function
  2. Blue and Red LED indicate various of status
  3. Simple and compact design
See more details of the productSee more details of the product

Model name：NPT-308LL

  1. Paper retraction function
  2. Blue and Red LED indicate various of status
  3. Simple and compact design
See more details of the productSee more details of the product

Model name：UPH-U250

  1. Firm structure to support large roll paper
  2. It comes with paper near end sensor.
  3. Paper width adjustable: 58 mm, 60 mm, 80 mm, 85 mm, 112 mm
See more details of the productSee more details of the product
