Face mount model
2 inch KIOSK printer

NP-F2092D

  • 12V駆動
  • 203dpi
  • USBインターフェイス
  • オートカッタ
  • シリアルインターフェイス
  • Paper width 58mm
NPF2092D_Eng

Product featuresProduct features

  1. 10 different paper positions are possible.
  2. Low price, super compact kiosk printer
  3. Arm position can be changed by users. (Upwards, backwards or downwards)
  4. Roll paper can be set at both the right and left by changing the arm part position.
  5. The printer position can be selected from either upright (printing side downward) or inverted (printing side upward).
  6. Low voltage operation DC12V
  7. Optional bezel is attachable.

Main specificationsMain specifications

Model name NP-F2092D
Print speed 100 mm/sec.
Number of dots / Line 384 dots
Paper width 58 mm
Print width 48 mm
Paper diameter 80 mm
Character International, Polish, Russian, Scandinavian, Turkish, Japanese
Barcode UPC-A, UPC-E, EAN-8, EAN-13, CODE39, CODABAR, ITF, CODE128,GS1 DataBar, QR code（model2）
Interface USB (V2.0 Full Speed) and Serial (RS232C)
Cutter Full cut and Partial cut by the command
External dimensions 98.8 (W) x 67.7 (D) x 132.4 (H) mm
Options BEZ-420

InquiryInquiry

If you have any question, please contact us.

OptionOption

Model name：BEZ-420

  1. Simple and low cost bezel
